Friday, May 20, 2011

PROJECT K-ON! Concert Stage Diorama (Part XXIV)

A Sneak peek on the lightings (which is 50% completed) for my K-ON! Concert Stage Diorama.

-click on the images to enlarge-










-Thank You for Viewing-

PROJECT K-ON! Concert Stage Diorama (Part XXIII)

WIP Lightings for the K-ON! Concert Stage Diorama: Part D
(making the main lightings for the concert stage)

Materials Used:
01. SSPVC Shelve Supply (Female)
02. Pla Plates
03. LED's
04. Push Button Knob (Black)
05. Nyko Surfacer Primer Gray, Flat Black, Black
06. Wires #22

-click on the images to enlarge-

-Pla Plates-
-LED's, etc for the project-
-SSPVC Shelve Supply (Female)-

-test fitting the pla plates & the LED's

-the painted projects-
-making a pcb design for the LED header-
-the pcb design for the LED header-
-making hole marks on the pcb before drilling-
-test fitting the LED's on the pcb board-

Now me & my brother is making an enclosure for this pcb. (using pla plates)
-trimming the pcb and the pla plate-
-the enclosure for the pcb with the holes for the LED's-

Now i'm sanding the built enclosure to smoothen out the edges.
-painted the LED cover with Nyko Black-
-test fitting the LED's-

-my work place while working on this project-
-this is me working on the wirings of the lightings-

-Thank You for Viewing-

PROJECT K-ON! Concert Stage Diorama (Part XXII)

WIP Lightings for the K-ON! Concert Stage Diorama: Part C
(making battery & flip flop circuit containers)

Materials Used:
01. Pla Plates
02. Nyko Surfacer Primer Gray, Flat Black
03. Bosny Black


-1st time in using pla plates, whoow! i love it so much!-
-this is the flip flop circuit container-
-the cover of the flip flop circuit container-
-the battery enclosure for the AA battery holder-
-after sanding the pla plates-
-primed all the scratch built containers-
-the AA battery holder with a toggle switch-

-the flip flop circuit container with the sliding cover-
-the container can hold 3 flip flop circuits-

-Thank You for Viewing-
